The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tyre pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the E-Bike; and the condition of the battery.
The bar below gives an approximate range. Conditions are categorized as extreme, good and ideal. Extreme conditions typically occur when riding with a heavy load, strong headwinds or excessive climbs.
Sizes
Small, Medium, Large, X-Large
Colours
Sea Sparkle
Frame
Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system
Fork
Fox 36 Factory E-Tuned, 29er, 150mm travel, 44mm offset, Grip2 VVC damper, Kabolt-X 110
Rear Shock
Fox Float X Factory, EVOL, 185x52.5mm Trunnion mount, custom tuned, recommended sag: 30%
Motor
Giant SyncDrive Pro2 Magnesium 85Nm, PedalPlus 6-Sensor technology
Controller
Giant RideControl Ergo3, grip integrated remote
Display
Giant RideControl GO, frame integrated LED console Optional wireless ANT+ display
Battery Type
Giant EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 200 range extender compatible
Battery Integration
Internal / Not Removable
Connectivity
N/A
Charger
Giant EnergyPak 4A smart charger, 60% in 1:45
Brake System
SRAM Code R Lever / SRAM Code R, 4-piston hydraulic disc, 220mm[F], 200mm[R]
Rear Derailleur
SRAM GX Eagle Transmission, AXS
Front Derailleur
N/A
Shifters
SRAM AXS Rocker Paddle, wireless electronic shifting 1x12
Bottom Bracket
Integrated into motor
Crankset
Praxis Carbon e-crank arms (S/M:160, L/XL:165) SRAM Eagle Transmission E-MTB Chainring , Steel 36T
Cassette
SRAM GX Eagle Transmission, 10-52T, 12-speed
Chain
SRAM GX Eagle Transmission Flattop Chain, Powerlock
Handlebar
Giant Contact SLR Trail, carbon, 800mm
Stem
Giant Contact SLR Trail, integrated,40/45/50mm Reach, 7/9degree Sweep Adjust System
Grips
Headset
Front Hub
E-TRA MTB Alloy Hub, 6 Bolt, 110x15
Rear Hub
E-TRA MTB Alloy Hub, 6 Bolt, 148x12 SRAM XD Drive Body Pawl Driver (Pawl 36x2 T) Thru-axle Thru-axle
Rims
E-TRX Hookless Tubeless ready Carbon 29 [F] / 27.5 [R] 30mm inner width
Front Tyre
Maxxis Minion DHF 29X2.50"" Foldable, TLR, EXO
Rear Tyre
Maxxis Dissector 27.5x2.4"" Foldable, TLR, EXO
Max Tyre Clearance
N/A
Seatpost
Tranz-X Rad+ 30,9mm, 30mm travel adjustable (S:120-150mm, M:140-170mm, L/XL:170-200mm)
Saddle
Giant Romero, Neutral
Pedals
Kickstand
N/A
Lighting
N/A
Lock
N/A
Carrier
N/A
Mudguards
N/A
Extras
MRP HD2 co-moulded chain guide, Tubeless kit (liquid, valves, levers, manual, tool) Inner tube supplied
Every effort has been made to ensure accuracy throughout this website. However, manufacturers reserves the right to change bike specifications, features, prices and colours without prior notice. If you would like to check the specification of a bike before purchasing, please call one of our stores.
