Sizes
XS, S: MX only, M, L: 29" F&R out of the box, MX compatible
Colours
Raw Carbon
Frame
Advanced-grade composite front and rear triangles, 150mm Maestro Suspension, 3 position flip, integrated down tube storage
Fork
Fox 36 Performance Elite, 160mm, Grip 2 damper, Boost 15x110 Kabolt, tapered, 44mm offset
Shock
Fox Float X Performance Elite 185x55, custom tuned for Liv
Handlebar
Giant Contact SLR TR35, composite, 20mm rise, 35mm
Grips
Liv Tactal Pro Single Lock-On
Stem
Giant Contact SL, 35mm
Seatpost
TranzX travel-adjustable dropper, remote XS&S: 120-150mm travel/ 30.9 x 459mm M&L: 140-170mm travel / 30.9 x 499mm
Saddle
Liv Sylvia
Pedals
PEDALS NOT SUPPLIED
Shifters
SRAM AXS, 1x12
Front Derailleur
N/A
Rear Derailleur
SRAM GX Eagle Transmission AXS
Brakes
Shimano XT BR-M8120, hydraulic, Shimano RT-66 rotors [F]203mm, [R]180mm
Brake Levers
Shimano XT BL-M8100
Cassette
SRAM GX T-Type, 10x52
Chain
SRAM GX T-Type
Crankset
SRAM GX T-Type, 30t, 55mm chainline
Bottom Bracket
SRAM DUB, press fit
Rims
Giant TRX 2 Carbon WheelSystem, 30mm inner width XS/S: [F] 29, [R] 27.5 M/L: [F] 29, [R] 29
Hubs
[F] Giant MTB alloy, 6-bolt, [R] Giant MTB alloy, 3-pawl driver, 6-bolt
Spokes
Sapim
Tyres
[F]: Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless Size XS and S, [R]: Maxxis Dissector 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless Size M and L, [R]: Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless
Extras
MRP chain guide, 3M tailgate protector, factory tubeless set up, integrated down tube storage bag, max tyre size 2.5", max chainring size 32t
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
