Sizes
SMall / Medium / Large / X-Large
Colours
Charcoal Plum
Frame
ALUXX SL-grade aluminum, 1.5"~1.8" head tube,125mm travel FlexPoint suspension system, 'Boost' 148x12 UDH rear axle, EnergyPak Plus Range Extender Compatible
Fork
SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
Rear Shock
SR Suntour Raidon R, 190x45mm, recommended sag: 30%
Motor
Giant SyncDrive Sport2, 75Nm, PedalPlus 6-sensor technology
Controller
Giant RideControl Dash, Smart Assist automatic mode, 5 support levels, USB-C (10W)
Display
Giant RideControl Dash, high-angle visibility, full color LCD display
Battery Type
Giant EnergyPak 625Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 250 range extender compatible
Battery Integration
Internal
Connectivity
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
Charger
Giant EnergyPak 4A smart charger compact, 60% charge in 2:30h
Brake System
Tektro HD-M745 Orion Levers / Tektro HD-M745 Orion, 4-piston, hydraulic disc, 203mm
Rear Derailleur
Shimano Deore LinkGlide, 10-speed
Front Derailleur
N/A
Shifters
Shimano Deore LinkGlide
Bottom Bracket
Integrated into motor
Crankset
FSA Comet E-Bike crank arm set FSA MegaTooth Direct-mount 1X steel 36T
Cassette
Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
Chain
Shimano, LinkGlide, CN-LG500
Handlebar
Giant Connect TR Riser 31.8x780mm
Stem
Giant Contact
Grips
Giant Connect ErgoMax lock-on
Headset
N/A
Front Hub
Giant eTracker Boost 110x15
Rear Hub
Giant eTracker Boost 148x12mm
Rims
Giant AM30, Tubeless ready, 30mm inner width [F] 27.5" (S size), 29" (M/L/XL size) [R] 27.5"
Front Tyre
Maxxis Rekon 27.5x2.4"(S size), 29x2.4" (M/L/XL size), Foldable, TLR, EXO, 60TPI
Rear Tyre
Maxxis Rekon 27.5x2.4" Foldable, TLR, EXO, 60TPI
Max Tyre Clearance
N/A
N/A
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Saddle
Giant Sport
Pedals
Aluminum Platform
Kickstand
Fitted
Lighting
Giant Rekon E50 HLAxa BlueLine Steady E6 rear
Lock
N/A
Carrier
Giant Rack-It MIK
Mudguards
Fitted
Extras
MRP HD2 co-moulded chain guide
Every effort has been made to ensure accuracy throughout this website. However, manufacturers reserves the right to change bike specifications, features, prices and colours without prior notice. If you would like to check the specification of a bike before purchasing, please call one of our stores.
