Frame: 24/30T Toray UD carbon / IS42-IS52 tapered headtube / 30mm main pivot bearings / 15mm Norglide linkage bearings / CNC alloy linkage / internal cable routing / signature TRL suspension design / Chip-Slot 2 dropout system / 130mm travel
Rear Shock: Fox Float DPS Performance / EVOL / 3 position adjust
Fork: Rockshox Revelation RL / 130mm travel / Solo Air / tapered alloy steerer /low speed compression to lock / rebound adjust / 15x100 / Maxle Stealth
Headset: FSA NO.42/ACB
Shifters: Shimano SLX M7000 Rapidfire Plus 1x11 speed
Rear Derailleur: Shimano SLX M7000 Shadow Plus
Chainset: Raceface AEffect / direct mount / 34T narrow wide 170-175mm
Bottom Bracket: Raceface X-Type
Chain: KMC X11L
Cassette / Freewheel: Shimano M7000 11 speed cassette 11-42T
Rims: Kore XCD SW 27.5 32h
Hubs: Formula DC-711 Boost sealed bearing 32h front / Formula DCL-300 sealed bearing 32h rear / Shimano E-Thru AX56 axle
Spokes: Double-butted stainless steel
Tyres: WTB Trail Boss TCS dual DNA light/fast 27.5 x 2.25" front / WTB Beeline TCS dual DNA light/fast 27.5 x 2.20" rear
Brakes: Shimano M615 180/160mm
Brake levers: Shimano M615
Handlebars: Kore Durox riser bar / 760mm wide / 20mm rise / 5 degree up bend / 8.5 degree back bend
Grips / Tape: Saracen lock-on grip
Stem: Kore Cubix / 65mm / A-head / 6 degree rise / 31.8mm clamp
Saddle: Kore Fazer EX
Seatpost: JD YSP12L dropper post / 120mm travel / internal cable routing / 30.9mm
